| Model | Sieve Size (cm) | Production (t/h) | Power (kw) | Weight (kg) | Dimensions (cm) | |
|---|---|---|---|---|---|---|
| Once | Second | |||||
| OCM 63×100 | 63×100 | 15 | 3 | 0.2×2 | 380 | 198×110×156 |
| OCM 80×150 | 80×150 | 25 | 5 | 0.2×2 | 450 | 248×110×156 |
| OCM 100×100 | 100×100 | 30 | 8 | 0.2×2 | 420 | 198×147×156 |
| OCM 100×150 | 100×150 | 45 | 12 | 0.37×2 | 500 | 248×147×156 |
| OCM 100×200 | 100×200 | 60 | 16 | 0.37×2 | 540 | 298×147×156 |
| OCM 150×100 | 150×100 | 50 | 12 | 0.37×2 | 540 | 198×197×144 |
| OCM 150×150 | 150×150 | 75 | 18 | 0.55×2 | 630 | 248×197×145 |
If you google “Oilseed Cleaning Machine”, you are probably losing 2–4 % oil yield because of hidden stones, metal nails and dust in your soybean or palm batches. This Guance Machinery shows how a cleaner recovers that loss, cuts wear on your screw press.
What the Market Calls It
Oilseed cleaner, oilseed pretreatment line, pre-cleaner, vibrating screener, specific-gravity destoner.
Why Cleaning Matters (Field Data)
1. 1 % stones → 0.6 % extra press cake moisture → 1.2 % oil left in cake.
2. 1 g Fe/kg seed → cutter bar life −30 %.
3. 0.5 % dust → neutral oil loss +0.3 % in refining plant.
Core Modules
1. Vibrating screener – 3 mesh layers, 3–25 mm openings, capacity 5–80 t/h.
2. Air separator – adjustable air knife, 0.3 m/s increments, removes husks & dust.
3. Magnetic drum – 7 000 Gs, automatic self-cleaning.
4. Gravity destoner – fluidized bed, 0.9–1.1 g/cm³ difference, no water needed.
Installation Notes from Our Engineer
1. Mount on rubber pads to keep vibration away from bucket elevator.
2. Pre-blend lots if moisture spread >2 %—dry surface kernels float and can be blown out.
Contact Guance Machinery for a free consultation and equipment quote within 24 h.
Oilseed cleaning Machine Advantages
1. >98 % impurity removal in one pass:
2. High capacity, low power: Cutting specific energy use by 20-30 % compared with traditional pre-cleaners.
4. Food-safe construction: 304 SS product-contact parts and food-grade seals; rust-free and cross-contamination-proof, ready for food or pharma lines.
Q1: How does an oilseed cleaning machine improve edible oil extraction yield?
A: The stand-alone seed cleaner lowers fiber and moisture variation, letting your oil press machine work at 2–4 % higher extraction rate and reducing wear on expeller parts.
Q2: Can the Oilseed Cleaning Machine run continuously for 24 h?
A: Yes, Designed for 24/7 operation.
Q3: Why should I clean my oilseeds before pressing instead of letting the screw oil press do the work?
A: A quick pass through a seed cleaner removes gritty bits that scratch your press, so your machine lasts longer and your final oil tastes cleaner—customers notice the difference.
