Guance Machinery is Screw Oil Press (Expeller) provided for continuous, high-efficiency oil extraction.
It is expertly engineered to handle a diverse range of oil, including palm, soybean, sunflower, canola, animal etc.
Applicable Oilseeds
Palm
Coconut
Olive
Sunflower
Rapeseeds
Soybean
Edible: palm fruit, soybean, sunflower, canola, cottonseed, peanut, sesame, coconut, flax, camellia, hemp, etc.
Industrial: palm kernel, jatropha, castor, neem, rubber seed, used cooking oil bleaching cake, etc.
Product Description
Guance Machinery oil press delivers a high oil output rate, produces minimal residue, and yields clear crude oil.
High-quality materials make up the machine, and quenching plus tempering harden the accessories for wear resistance and long service life.
A special helical-gear design drives the gearbox, keeping the load small, power consumption low, and operating noise minimal.
YZYX 168
YZYX10-6/8/9
Main Specifications
| Model | Capacity(t/d) | Power(kw) | Measurement(L*W*H)(mm) | Rotate Speed(r/min) | Residual Oil(%) | Weight(kg) |
|---|---|---|---|---|---|---|
| YZYX70 | 1.3 | 4 | 1180*405*1120 | 33~42 | ≤7.8 | 195 |
| YZYX90 | 3 | 5.5 | 1250*550*1140 | 32~42 | ≤7.8 | 285 |
| YZYX10 (95) | 3.5-4 | 7.5 or 11 | 1650*730*1340 | 32~40 | ≤7.8 | 528 |
| YZYX10-6/8/9 | 4.5 | 11 | 1760*730*1340 | 32~40 | ≤7.8 | 590 |
| YZYX120 | 6.5 | 11 or 15 | 1860*740*1275 | 28~40 | ≤7.0 | 680 |
| YZYX130 | 8 | 15 or 18.5 | 2020*742*1420 | 32~40 | ≤7.6 | 825 |
| YZYX140 | 9~11 | 18.5 or 22 | 2010*750*1430 | 32~40 | ≤7.6 | 806 |
| YZYX 168 | 20 | 37 or 45 | 2750*1100*1830 | 36~46 | ≤7.4 | 1820 |
Screw Oil Press Machine Advantages
: Low initial cost, suitable for small businesses, enabling quick startup in oil extraction production.
Simple Supporting: Simple structure, few spare parts, easy support, saving maintenance costs and time.
Easy to Maintain: Easy operation and maintenance, reducing equipment failure, improving efficiency, and lowering maintenance expenses.
Wide Applicability: Suitable for various oil crops, meeting diverse market demands and enhancing production versatility.
High Oil Yield: High oil extraction rate, efficiently squeezing raw materials, boosting profitability, and ensuring product quality.
Extend Service Life
Other Knowledge
The importance of oil press to oil mill
The While you set up oil mill, the seed-oil expeller takes charge: it dictates capacity, automation scale, oil quality and every other commercial decision.
Guance Machinery invest heavily in research and development, apply deep know-how and continually refine the worm profile, screw taper and compression ratio so their presses deliver higher output and superior oil for any scale of operation.
We engineer each press to squeeze more oil and leave less fat in the cake, then we build the range outwards: bench-top units for test batches, mid-size mills for local cooperatives, and high-capacity tandem lines for industrial plants. Customers choose the scale, we deliver the machine that fits.
Get a Quick Quote
Contact Guance Machinery tell us your seed type, target tonnage and power supply. Detailed quotation will reach you within 24 hours.
